HuiNuo HN-SPC8-E heating type Spinning Coater aluminum alloy anodic oxidation + heating baking glue

Speed range 0~10000rpm, Acceleration range 100~5000rpm/s, Rotation speed resolution 1rpm, cavity material aluminum alloy, glue drop mode manual glue drop, heating temperature RT +~ 200 ℃, heating part cover heating.

$5978.00/set

PromotionLoading...

Coupon

Model：

HN-SPC8-E

Certificate

HuiNuo

Chinese general agent

Contact

Details SPEC Con

HuiNuo HN-SPC8-E Heated Spinning CoaterSPEC

HuiNuo HN-SPC8-E Heated Spinning CoaterDetails

HuiNuo HN-SPC8-E Heated Spinning CoaterPacking list

SKU: NB049989

Speed range: 0~10000rpm

Acceleration range: 100~5000rpm/s

Rotation speed resolution: 1rpm

single step time: 3000s

Suitable substrate: Diameter ≤ 8 inches (200mm)

Cavity material: aluminum alloy

Epoxy method: Manual glue drop, optional precision syringe pump

Linear dispersion: Linear dispersion 5 segments each, a total of 5 Linear dispersions can be stored

pumping rate: 50L/min

vacuum pump: Dry mechanical pump

heating temperature: RT+~200℃

Heating part: Upper cover heating

Power supply Voltage: AC220V 50/60Hz

Extraction port: φ 6mm quick screw interface

Human Machine Interface: 7 inch high definition LCD touch screen

Machine Weight: 12kg

Machine size: 290*365*300mm

HN-SPC8-E

Heated Spinning Coater

Product Introduction

HN-SPC8-E heated homogenizer adopts all-aluminum alloy cavity, which is beautiful and sturdy. The instrument adopts advanced precision motor, and the speed can reach 10,000 rpm, which effectively guarantees the uniformity of film formation. In addition to the basic spin coating function, this product is also equipped with a heating element, which can be heated up to 200°C, and the temperature is controlled by the intelligent temperature control meter, the temperature measurement is accurate, and the heating process is completely controllable. In addition, this instrument adopts touch screen control, which can preset the homogenization curve, which greatly simplifies the use process and reduces the learning cost, which is very suitable for laboratory purchase.

Scope of application

Liquid or colloidal materials can be coated on silicon wafers, crystals, quartz, ceramics and other substrates to form thin films, which are mainly used in photoresist spin coating, biological medium production, sol-gel production of polymer films and other fields.
