Specifications
| light output area | 300mmX200mm |
| wavelength | 365/385/395/405 (optional) |
| Power density | 365 /385nm 0.5W/cm ² (10mm irradiation distance), 395/405nm 0.8W/cm ² (10mm irradiation distance) |
| Heat dissipation method | air-cooled |
| Control mode | PLC control |
| Power regulation | Digital dimming (1-100%) |
| power consumption | 600W |
| parameter setting | Touch screen operation |
| Lamp bead life | ≥20000H |
| Lamp bead brand | Seoul, South Korea |
| Dimension | L635mm*W520mm*H520mm |
| lumen size | L330mm*W240mm*H160mm |
| Environmental temperature and Humidity | Environmental temperature: -10 ℃ -50 ℃ Relative Humidity: 25% -80% RH |
| Power supply Voltage | AC100V-AC240V (50/60HZ) |
| Net Weight | 41KG |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49993/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
