Specifications
| Coating method | Wire rod + scraper |
| coating rate | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate fixing method | Vacuum adsorption + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 740*530mm |
| Effective coating area | 500 * 500Mm (can be customized) |
| Wire bar coating thickness range | Different rod numbers have different thicknesses, with high-precision imported wire rods |
| Wire rod coating Accuracy | ±0.003mm |
| Scraper coating thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Scraper material | Die steel |
| Scraper coating width | 500mm |
| Scraper coating Accuracy | ±0.003mm |
| Vacuum Area | 580 * 460Mm (can be customized) |
| vacuum aperture | Φ0.8mm |
| Vacuum hole spacing | 20*20mm |
| Pumping Speed | 5.4m3/h |
| Ultimate Vacuum | 50KPa |
| Vacuum pump power | 180W |
| Vacuum pump Weight | 7.1kg |
| Drive motor | Servo motor |
| power | 600w |
| operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 220V/50HZ (can be customized 110V/60HZ) |
| external Dimensions | 760*640*430mm |
Packing list
film coating machine x1, wire rod x1, scraper x1, vacuum pump x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
