Specifications
| Spreader mode | Wire rod + scraper |
| Spreader rate | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate fixing method | Vacuum adsorption + fixture |
| Spreader material | Surface hard treatment aluminum alloy |
| Spreader size | 1040*830mm |
| Effective Spreader Area | 800 * 800Mm (can be customized) |
| Spreader Film thickness range | Different rod numbers Film thickness is different, with High Accuracy imported wire rod |
| Spreader accuracy | ±0.001mm |
| Spreader Film thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Scraper material | Die steel |
| Spreader Width | 800mm |
| Spreader accuracy | ±0.003mm |
| Vacuum adsorption size | 880 * 760Mm (can be customized) |
| vacuum aperture | Φ0.8mm |
| Vacuum hole spacing | 20*20mm |
| Vacuumpump pumping rate | 5.4m3/h |
| ultimate vacuum | 50KPa |
| Vacuumpump power | 180W |
| Vacuumpump weight | 7.1kg |
| Heating method | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| Drive motor | Servo motor |
| operating language | Chinese (can be customized in English) |
| display screen | Color LCD touch screen |
| Host power supply | 100V~220V/50~60HZ |
| power | 1800w |
| Dimension | 1060*940*430mm |
| weight | 40kg |
Packing list
Host X1, manual X1, scraper x1, imported wire rod X1, certificate X1, Vacuumpump X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
