Specifications
| screening series | Level 5 |
| Screener Capacity | 10 liters (the Volume of one classifier) |
| Stirrer Rotation speed is | （580±1）r/min |
| Screening mesh (factory selection of medium and long fibers) | Tyler sieve 14 mesh, 28 mesh, 48 mesh, 100 mesh |
| Flow rate of water is | 0~20L/min adjustable (according to the standard adjustment used in the experiment), display Accuracy 0.5% R |
| screening time | Adjustable from 0 to 9999min (according to the standard adjustment used in the experiment) |
| main material | 304 stainless steel |
| Dimension | 1300Mm (length) × 520mm (width) × 1400mm (height) |
| Net Weight | 130Kg |
| Water source status | We need a continuous water source. |
| Power Supply | 240W/380V |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 3650 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50215/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
