Specifications
| Coating Method | Bar + drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Carbide aluminum alloy baseplate (optional Glass plate) |
| Coating table size | 1240*830mm |
| Effective coating Area | 1000 * 800Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Bar Accuracy | ±0.001mm |
| Drawdown blade Coating thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 800mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Drive motor | Servo motor |
| Power | 400w |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Dimension | 1260 * 940 * 940Mm (subject to the actual product) |
| optional feature | Heating Vacuum chuck |
Packing list
Host X1, manual X1, fixture X1, drawdown blade x1, import bar X1, certificate X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50233/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
