Specifications
| test force | 500, 1000, 2000, 3000N optional |
| Operation mode | Five-inch Color LCD Touchscreen, |
| Standard test force | 500N |
| Measurement range | 2% of maximum test force - 100% |
| Accuracy level | ±1% |
| Test Force Precision | +/- 1% better than indication |
| deformation display error | ≤±(50+0.15L) |
| test force | Minimum resolution 0.01N |
| Displacement measurement | Resolution is 0.01mm |
| Deformation Precision | Better than +/- 1% |
| LCD content | Test force, displacement, peak value, operating state, operating speed, etc |
| stepless speed regulation | Stepper Motor and Control system |
| Drive mode | Stepper motor, synchronous belt drive |
| Motor Power | 150W |
| Speed range | 1mm/min~~500 mm/min |
| Test Travel | 400Mm/800mm (standard 800, customizable) |
| stretch space | 400Mm/800mm (standard 800, customizable) |
| Host size | 500*420*1550mm |
| Test protection function | Overload protection, leakage protection, limit protection |
| Power supply | 220V 50Hz |
| Weight | About 80Kg |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50250/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
