Specifications
| Spreader size | Max.L200mm*W300mm |
| substrate size | L430mm*W320mm |
| Mechanical speed | Traverse speed 1-200mm/s |
| Film thickness | Max：5mm |
| Feed Capacity | Stainless steel syringe (Max: 60ml) |
| Feeding speed | 0.05-5 mm/s (barrel piston speed) optional |
| Installation size | L740mm*W444mm*H425mm |
| Film thickness | 40mm |
| Heating range | Room temperature -200 ℃ |
| Weight | About 90Kg |
| Accuracy | ±2um |
| viscosity | 100-7000mPas |
| bottom | Heating range 0-200 ℃, temperature control Accuracy +/- 1 ℃ |
| gap | 10Um-10mm adjustable, adjustment Accuracy 1um |
| Coating method | extrusion coating |
| Lip height | 0~5Mm, adjustable |
| Adjustment Accuracy | A. Digital dial: 1um |
| Coating Accuracy | +/- 2μm (reference value depends on slurry characteristics) |
| Die head model | TG-C200 |
| Die head material | SUS630 |
| Die Accuracy | Lip straightness ≤ 3μm |
| cavity Volume | 8ml |
| gasket width | Opening width Max. 200mm |
| Film thickness | 30/50/70/100/200um (Film thickness is selected according to solution viscosity) |
| Power Supply | Single Phase AC110 - 220V +/- 10%, Frequency 50/60Hz, Power 300W |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50302/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
