Specifications
| Coating Method | Drawdown blade Spreader |
| Spreader head | Front and rear Dual Blade combination |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | aluminum alloy |
| Coating table size | 940*630mm |
| Applicable substrate Film thickness | ≤ 40mm (customized heightening bracket) |
| Effective coating Area | 700 * 600Mm (can be customized) |
| Drawdown blade Spreader Film thickness range | 0~10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade Spreader width | 600mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| power | 400w |
| Display | Color LCD touch screen |
| operating language | Chinese (can be customized in English) |
| Host Power Supply | 100V~220V/50~60HZ |
| Dimensions | Subject to the actual product |
| optional feature | Heating, Vacuum chuck |
Packing list
Machine x1, adjustable drawdown blade x2, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50391/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
