Specifications
| frequency | 50/60HZ |
| display mode | OLED display |
| display content | Speed, time, power display |
| Max. Capacity of stirring (H2O) | 1L |
| Maximum Stir Size | 30 mm |
| Standard Stir Specifications and Dimensions | Type C Ø 7 * 20 mm (for use above 700rpm) + Type B Ø 8 * 30 (for use below 700rpm) |
| forward and reverse function | Yes. |
| control mode | Point Press + Slide |
| Motor type/drive mode | Magnetic coil |
| Magnetic coil | 15～ 1500rpm |
| Time fixed range min | 1~ 99min59s, 0 normally open |
| Reverse Timer Range | 20～ 99s |
| Panel Material | Tempered Glass |
| Pan size | Φ100 mm |
| shell material | ABS+TPU |
| Shell dustproof waterproof protection class | IP67 |
| Power Supply | Input 110~240V output 5V 2A/lithium battery |
| net Weight | 0.25kg |
| Product size (L × W × H) | 170×110×16mm |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50398/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
