Specifications
| power | 1500W |
| Volume Flow | 308-100L/min |
| rated pressure | 0.8Mpa |
| starting pressure | 0.5Mpa |
| shutdown pressure | 0.8Mpa |
| output pressure | (0.1-0 adjustable) |
| Speed r/min | 1400 r/min ±50 |
| Vibration intensity mm | ≤0.5 mm |
| Operating environment Temperature ℃ | -5~45℃ |
| Unit motor temperature rise ℃ | ≤50℃ |
| Energy saving grade | Grade II |
| gas tank | 60L |
| Outlet temperature | Environment Temperature +/- 10C ° |
| Air outlet size | Outer diameter 88mm Inner diameter 5mm |
| Air compressor compression level | single stage |
| Drive mode | Motor drive |
| oil content | 0.0 PPM (pure oil-free) |
| Dust filtrates granularity | 0.1μm |
| noise | 52dB±2 |
| net Weight | 60KG |
| Voltage V/Hz | 220V/50HZ (10A power plug) |
| Product size | 50*50*75cm |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
