Specifications
| Coating Method | Bar Spreader |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Aluminum alloy/Glass table (if the specified material is confirmed with customer service) |
| Coating table size | 600*300mm |
| Effective coating Area | 400 * 300Mm (can be customized) |
| Film Film thickness | Controlled by bar, with high Accuracy import bar |
| Meyer rod coating Accuracy | ±0.001mm |
| Drive motor | Servo motor |
| power | 600w |
| UV curing area | 400*300mm |
| UV light main peak wave | 365nm |
| UV light power | 400*2W |
| UV light curing wavelength | 350-450nm |
| switch | Aviation plug/separate switch |
| Light source spacing | 18*18mm |
| Lamp board height from coating table | 20Mm (support customized adjustable height) |
| Light type | LED |
| operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 220V/50HZ (can be customized 110V/60HZ) |
| optional feature | Drawdown blade, heating, Vacuum chuck |
| Dimensions | 658*438*205mm |
| Weight | 39.7kg |
Packing list
Host X1, manual X1, fixture X1, imported bar X1, certificate X1
After-sales instructions
Warranty days: 730 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50442/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
