Specifications
| application width | 300 mm (Spreader maximum width, slightly narrower on demand) |
| Substrate type | Metal foil (copper/aluminum), Plastic film (PET/PI, etc.), Non-woven fabric, etc |
| substrate thickness | 0.010~ 0.200 mm (reference value, adjustable) |
| Coating Method | Adjustable drawdown blade, cutter head can be quickly removed |
| Spreader thickness | 0.1~ 2Mm (adjustable, resolution 0.001mm) |
| Spreader Accuracy | ±0.005mm |
| Blade material | High strength, abrasion resistant stainless steel (with 4 blades) |
| roll diameter | Max. Ø 300 mm (inflatable shaft type) |
| winding diameter | Max. Ø 300 mm (inflatable shaft type) |
| Spreader speed | 1 - 10 m/min (stepless speed regulation) |
| Drying method | Hot air circulation oven, divided into 3 sections, 1 meter each, independent temperature control |
| Heating mode | Electric blast drying |
| Temperature range | Room temperature~ 200 ° C (can be adjusted according to requirements) |
| Temperature control Accuracy | ±1°C |
| Control system | PLC + touch screen |
| Total Power | About 15-25 kW (subject to actual customization) |
| Device size | About L6000 x W600 x H1500 mm (subject to actual customization) |
| Device Weight | About 800 - 1000 kg (subject to actual customization) |
Packing list
Host x1, Spreader head x4, Manual x1, Encasement list x1, Certificate of conformity x1
After-sales instructions
Warranty days: 365 days
