Specifications
| Coating Method | continuous scratch coating |
| Effective application width | ≤ 300mm, adjustable through baffle |
| Drawdown blade adjustment | manual adjustment |
| Spreader roller diameter | Ф50mm |
| Spreader thickness range | 0.01mm~2mm |
| Minimum gluing thickness | 0.01Mm (depending on the slurry, refer to the material requirements) |
| Coating surface density | ≤ +/- 1.5% (including substrate, excluding edge anomalies) |
| Coating Speed | 2~ 4.5M/min forward and reverse stepless transmission |
| Film Accuracy | +/- 0.003mm (depending on slurry, reference material requirements) |
| Regulator resolution | 0.001mm |
| Indication Display mode | digital display |
| Heating device | Chute heating |
| Heating mode | Heating rod |
| Temperature range | RT+~200℃ |
| box Volume | About 0.5L |
| Width of guide roller | 300mm |
| substrate width | Max.300mm |
| Back roller diameter | Ф150mm |
| Reel diameter | 3 inches. |
| rewinding diameter | Max.Ф450mm |
| Applicable materials | hot-melt adhesive |
| Machine Power | 1050W |
| Host Power Supply | AC220V (single phase) 50Hz |
| Machine size | 1051*635*600mm |
| Machine Weight | About 120kg |
Packing list
Equipment machine × 1, dial meter x2, power cord × 1, warranty card & manual x1, certificate of conformity x1
After-sales instructions
Warranty days: 365 days
