Specifications
| Voltage/Frequency | 220V/50Hz |
| Rated Power | 1000w |
| Furnace size (L × W × H) | 100×100×100mm |
| maximum positive pressure | ≤ 0.02MPa |
| Furnace material | Aluminum oxide ceramic fiber |
| Furnace load bearing | 5Kg |
| Heating components | resistance wire |
| Heating rate adjustment range | 0℃ /min~30℃ /min |
| recommended Heating rate | ≤ 10℃ /min |
| Operating temperature | 300~1100℃ |
| Temperature control Accuracy | ±1℃ |
| Thermocouple | Thermocouple K |
| Material carrier material | Quartz crucible |
| Door opening method | Handwheel side opening |
| Net Weight | 83Kg |
| Product size (L × W × H) | 547×490×769mm |
