Specifications
| Voltage/Frequency | 220V/50Hz |
| Rated Power | 3000w |
| Furnace size (L × W × H) | 200×150×150mm |
| maximum positive pressure | ≤ 0.02MPa |
| Furnace material | Aluminum oxide ceramic fiber |
| Furnace load bearing | 5Kg |
| Heating components | resistance wire |
| Heating rate adjustment range | 0℃ /min~30℃ /min |
| recommended Heating rate | ≤ 10℃ /min |
| Operating temperature | 300~1100℃ |
| Temperature control Accuracy | ±1℃ |
| Thermocouple | Thermocouple K |
| Material carrier material | Quartz crucible |
| Door opening method | Handwheel side opening |
| Net Weight | 146Kg |
| Product size (L × W × H) | 605×630×870mm |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50531/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
