Specifications
| Voltage/Frequency | 220V/50Hz |
| Rated Power | 9000w |
| Furnace size (L × W × H) | 300×200×200mm |
| maximum positive pressure | ≤ 0.02MPa |
| Furnace material | Aluminum oxide ceramic fiber |
| Furnace load bearing | 10Kg |
| Heating components | silicon carbide rod |
| Heating rate adjustment range | 0℃ /min~≤ 20℃ /min |
| recommended Heating rate | ≤ 5 ℃ /min (1000-1500 ℃) |
| Operating temperature | 300~1250℃ |
| Temperature control Accuracy | ±1℃ |
| Thermocouple | S-type Thermocouple |
| Material carrier material | Corundum crucible |
| Door opening method | Handwheel side opening |
| Net Weight | 206Kg |
| Product size (L × W × H) | 645×740×980mm |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50535/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
