Specifications
| Voltage/Frequency | 380V/50Hz |
| Rated Power | 16000w |
| Furnace size (L × W × H) | 400×300×300mm |
| maximum positive pressure | ≤ 0.02MPa |
| Furnace material | Aluminum oxide ceramic fiber |
| Furnace load bearing | 10Kg |
| Heating components | silicon carbide rod |
| Heating rate adjustment range | 0℃ /min~≤ 20℃ /min |
| recommended Heating rate | ≤ 2 ℃ /min (greater than 1500 ℃) (the higher the temperature, the slower the Heating rate is recommended) |
| Operating temperature | 300~1250℃ |
| Temperature control Accuracy | ±1℃ |
| Thermocouple | S-type Thermocouple |
| Material carrier material | Corundum crucible |
| Door opening method | Handwheel side opening |
| Net Weight | 333Kg |
| Product size (L × W × H) | 805×875×1110mm |
