Specifications
| Core power and working parameters | / |
| Motor Power | 7.5 kW (7500W) |
| Motor type | Explosion-proof three-phase asynchronous motor (optional, suitable for flammable and explosive environments) |
| Power Specifications | 3-Phase, 380V/50Hz (can be customized according to customer needs) |
| Rotation speed | 0~1440 rpm (frequency conversion speed regulation, recommended working interval 500~1200 rpm) |
| Stirring shaft form | Single axis, bottom tray impeller and grinding tray integrated design |
| Cartridge and grinding system parameters | / |
| Nominal Volume of material barrel | 100 L |
| Effective working Volume | 70 to 80 L (recommended load to allow room for expansion and circulation) |
| Barrel material | Inner cylinder SUS 304 stainless steel (standard) or SUS 316L stainless steel (corrosion resistance) |
| Jacket design | With chill down/heating jacket |
| Jacketed medium | Chill down water or heat transfer oil (for material temperature control) |
| Working pressure of jacket | ≤ 0.3 MPa |
| Third, grinding basket and grinding medium parameters | / |
| Ground basket structure | Bottom open turbine construction with powerful suction pump effect |
| Grinding basket material | stainless steel |
| Grinding basket diameter | ~ φ 220 mm (estimate, according to barrel size) |
| Number of dispersion discs | Multilayer serrated dispersion discs (usually 2-4 grades) |
| Grinding medium | Available Zirconia Beads, Glass Beads, Steel Beads, etc |
| Diameter of grinding medium | 0.8 mm~ 2.0 mm (according to fineness requirements) |
| media fill | About 30~50 L (70% -80% of the Volume of the grinding basket) |
| IV. Mechanical structure and external parameters | / |
| Equipment Dimensions (Length × Width × Height) | About 650 mm × 600 mm × 1500 mm (subject to actual customization) |
| Net Weight of equipment | About 380 kg (subject to actual customization) |
| rack structure | Heavy carbon steel welded channel or square tube with anti-rust finish |
| Lifting method | Electric lift |
Packing list
machine x1, barrel x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
