Specifications
| Processing samples | E. coli, yeast, insect cells, etc |
| Feed size | ＜500μm |
| Flow rate | 5-15L/h |
| design pressure | 2000bar |
| Working pressure | 1500bar |
| Power | 1.5kW |
| Processing Capacity | 60ml-15L/h |
| Processing Capacity | 60ml |
| product viscosity | ＜2000cP |
| Feed temperature | ＜90℃ |
| dispersion series | first level |
| pressure gauge | Hygienic pressure sensor |
| Accuracy | 1bar |
| Main motor | Swiss ABB/SIEMENS 1.5kW 8-class motor |
| Voltage and Frequency | 220V, 50Hz, three-phase |
| level | Sanitary grade |
| plunger | 1 piece |
| Internal chill down | Fan |
| Inlet and outlet connection | Tri-Clamp Quick Connect |
| Maximum cleaning temperature | ＜90℃ |
| Maximum sterilizing temperature | ＜145℃ |
| Cleaning/sterilizing time | 30min |
| Water consumption during cleaning/sterilizing | 30L/h |
| Dimensions (W * H * L) | 785*450*475mm |
| Packaging Dimensions (W * H * L) | 880*630*650mm |
| Net Weight | 110kg |
| Gross Weight | 180kg |
| chiller | Standard |
| Sink Volume | 2.1L |
| Temperature range | -20℃~RT |
| No-load minimum temperature | -20℃ |
| Temperature control Accuracy | ±1℃ |
| cooling Capacity | -20℃（120W） -10℃（280W ） 0℃（460W） 20℃（700W） |
| 120W | 280W |
| circular interface | Outer diameter 10mm (pagoda type) |
| Maximum Circulating Flow rate | 11L/min |
| head | 8M |
| pressure | 0.4bar |
| Storage tank material | SUS304 |
| refrigerant | R404A |
| Shell material | Cold plate electrostatic spraying SPCC |
| drain valve | Yes. |
| Liquid level indicator window | Yes. |
| Rated Power | 420W |
| Environmental temperature | 5-35℃ |
| power requirements | 220V 50Hz |
| Dimensions (length * width * height) | 445*265*535mm |
| Packaging Dimensions (L * W * H) | 500*310*600mm |
| Net Weight | 30kg |
| Gross Weight | 50kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50556/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
