Specifications
| Max. stirring Capacity | 60L |
| Speed range | 30-2200rpm |
| Display Accuracy | ±1rpm |
| program control | 3 program settings (Rotation speed, time, forward and reverse) |
| screen display | 4.3 inch LCD capacitive touch screen |
| Speed regulation mode | coarse + fine tuning |
| Time fixed range h | 0~08:00:00 |
| Torque display | Torque with trend display function |
| Max Torque N.cm | 80 |
| Maximum viscosity mpa.s | 80000 |
| Input Power W | 160 |
| Output power W | 150 |
| Protection level | IP42 |
| forward and reverse function | Depending on the type of Impeller, swirl/spin direction can be selected |
| Sample temperature protection | Measurement of sample temperature, setting the maximum temperature limit of sample protection -160~600 ℃ |
| software interface | Type-C, RS485, dedicated software for remote control and data management |
| Motor protection | Display fault automatic stop |
| Overload protection | Display fault automatic stop |
| Safety protection | chuck protective cover + non-slip pad |
| Allowable Environmental temperature ℃ | 5~40 |
| Environmental humidity% | 80 |
| Main instrument size mm | 210*100*290 |
| Packaging Dimensions mm | 470*345*205 |
| Packaging Dimensions mm | 810*400*140 |
| Net Weight kg | 5 |
| Host instrument Gross Weight kg | 6 |
| Net Weight kg | 16 |
| Set instrument Gross Weight kg | 18 |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50564/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
