Specifications
| Measurement principle | Ultrasonic pulse reflection |
| Frequency | 5MHz |
| Measurement range | 1~ 300Mm (steel) |
| Measurement mode | Continuous measurement |
| Speed of sound | 1000~9999m/s |
| resolution | 0.1mm |
| Accuracy | 1.0 to 9.9mm: +/- 0.1mm 10.0 to 299.9mm ： +/- ( 1% reading + 0.1mm) EC-2000-C: 300.0 to 400.0 mm ： +/- ( 2% reading + 0.10mm) Miscellaneous range indication for reference only |
| Support probe | PU5-10 |
| unit | Mm mm, inch |
| reaction time | Single measurement about 0.5 seconds, continuous measurement about 0.3 seconds |
| Storage Capacity | 60 sets of data |
| Calibration method | 4Mm calibrated |
| show | Segment screen with backlight |
| Operating environment | Temperature: -10~ 50 ℃; Humidity: ≤ 90% RH, no condensation |
| Storage environment | Temperature: -20~ 60 ℃; Humidity: ≤ 90% RH, no condensation |
| Power Supply | 3 AA 1.5V alkaline batteries; USB 5V/2A (Type-C interface) |
| Protection level | IP40 |
| Dimension | 135*72*27mm |
| Shell material | ABS |
| Weight | Approximately 127g (without battery) |
| Probe model | PU5-10 (standard) |
| Probe type | Ordinary probe |
| Frequency | 5MHz |
| Measurement range | Determined by the host |
| Minimum measurement area | Diameter 15mm |
| contact temperature | -10~60℃ |
| Line length | About 1m |
| Weight | About 45g |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50592/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
