Specifications
| Inner box size | Width 350x Depth 350 x Height 400mm |
| Outer box size approx | Width 1470x Depth 1420x Height 1830mm |
| Impact Temperature range | -40 ℃~~ + 150 ℃ adjustable |
| Temperature Impact Time | Temperature Impact in 5 Minutes |
| Temperature range of cold storage zone | -60 ℃ adjustable |
| Temperature range of regenerative zone | 180 ℃ adjustable |
| Cooling rate | 1 ℃ min (no-load nonlinear) |
| Heating rate | 2-3 ℃ min (no-load nonlinear) |
| temperature stability | ±0.5℃ |
| Temperature deviation | ± 2℃ |
| Power supply Voltage | 380V 50-60HZ 10-16KW(14.5) |
| Zone 3 temperature | Experimental area, preheating area, precooling area |
| temperature recovery time | 5Min Weight 550KG |
| Experiment box | The test object is placed in the test area for testing. |
| warm-up area | The high temperature zone is responsible for heat storage |
| pre-cooling area | Negative cold storage in low temperature region |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50603/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
