Specifications
| Coating Method | Bar + drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum chuck + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | Subject to the actual product |
| Effective coating Area | 210 * 150Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Meyer rod coating Accuracy | ±0.001mm |
| Drawdown blade Coating thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 150mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Vacuum chuck size | 290 * 110Mm (subject to actual customization) |
| Vacuum Aperture | Φ0.8mm |
| Vacuum hole pitch | 20*20mm |
| Heating mode | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Heating Temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| Pumping Speed | 27L/min |
| Ultimate Vacuum | -95KPA |
| Motor type | Closed loop motor |
| Vacuum Pump Power | 180W |
| Vacuum pump Weight | 7.1kg |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Power | 1800w |
| Dimension | 470 * 290 * 430Mm (excluding tool holder) (subject to actual customization) |
| Weight | About 30kg, subject to the actual product. |
Packing list
Host X1, manual X1, drawdown blade x1, import bar X1, certificate X1, vacuum pump X1
After-sales instructions
Warranty days: 730 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50605/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
