Specifications
| Probe tip | cemented carbide |
| Measurement principle | Fe: magnetic Induction NFe: eddy Current |
| Probe type | Built-in integrated |
| Measurement range | 0.0-2000μm |
| resolution | 0.1μm:（0μm - 99.9μm）1μm:（100μm - 2000μm） |
| Measurement Accuracy | 0-1000 μm ：≤ +/- ( 2% H + 1 μm), H is Standard value 1000-2000 μm ：≤ +/- 3% H, H is Standard value |
| unit | μm / mil |
| Measurement interval | 0.3s |
| Minimum measurement area | Ø = 15mm |
| minimum matrix thickness | Fe:0.2mmNFe:0.05mm |
| show | 128 × 48 point array LCD |
| Power supply method | 2 1.5V AA alkaline batteries |
| Operating temperature range | 0℃-50℃ |
| Temperature range | -20℃-60℃ |
| Host size | 90*65*28 mm |
| Weight (with battery) | 123g |
| supply voltage | DC3V |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50613/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
