Specifications
| Coating Method | Bar Spreader |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum chuck + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 450 * 180Mm (subject to actual customization) |
| Effective coating Area | 210 * 150Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Meyer rod coating Accuracy | ±0.001mm |
| Vacuum Area | 290 * 110Mm (subject to actual customization) |
| Vacuum aperture diameter | Φ0.8mm |
| Vacuum hole pitch | 20*20mm |
| Vacuum pump pumping rate | 5.4m3/h |
| Ultimate vacuum degree | 50KPa |
| Vacuum Pump Power | 180W |
| Vacuum pump Weight | 7.1kg |
| Drive motor | Servo motor |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host power supply | 220V/50HZ (can be customized 110V/60HZ) |
| Power | 600w |
Packing list
Host X1, manual X1, imported bar X1, certificate X1, vacuum pump X1
After-sales instructions
Warranty days: 730 days
