Specifications
| Sampling size | 100*100mm |
| Sampling thickness | 0.0045~1.0mm |
| Parallelism error on both sides | ＜0.03mm |
| Parallel accuracy | 0.05 ±0.01 mm |
| positioning torque ratio | 31:11 |
| Sample feeding height | 5mm |
| Blade Hardness | Blades can be used to cut steel blades |
| Sampler mode | Manual vertical stamping sample preparation |
| notch parallelism | ≤0.1mm |
| Sampling table panel material | 304 stainless steel |
| Blade | Special treatment mold SKD11, non-special high-strength materials or man-made damage, can be replaced without blade for 2 years. |
| Blade processing technology | Triple high temperature quenching, triple fine grinding |
| Dimension | 400*350*300mm |
| weight | 35kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50647/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
