Specifications
| Spreader process | Unwinding and scraping → Extruding Dampener Roller and Gel Tank Cleaning 1 → Cleaning 2-Air Knife → Oven 2 meters → Deviation correction → Winding |
| Effective Spreader Width | Max.Φ350mm |
| coating method | Adjustable scratch coating |
| Cutting head type | Film thickness adjustable |
| Indication display | digital display |
| wet film thickness | 0.005-3mm |
| Regulator Graduation | 0.001mm |
| Spreader accuracy | ±5% |
| coating speed | 1-10M/min (adjustable) |
| unwinding method | Inflatable shaft unwinding |
| winding method | Inflatable shaft winding |
| Outer diameter of winding air expansion shaft | 3-Inch expansion shaft, load-bearing 50KG |
| maximum discharge | Max.Φ350mm |
| maximum charge | Max.Φ350mm |
| Drying temperature range | RT+~200℃ |
| Temperature control accuracy | ±3℃ |
| Heating method | hot air circulation |
| Oven length | 1M/section * 1 |
| Total length of drying tunnel | 2m |
| Drying power | 1KW/section |
| Tension control range | Automatic constant tension (1-10N) |
| Tension control accuracy | ±0.5N |
| Motor type | Servo motor |
| control mode | PLC + Touchscreen |
| Human Machine Interface | Color Touchscreen |
| tension control | automatic |
| correction control | automatic |
| Film thickness control | manual |
| soak | With soaking function |
| soaking size | Soak 1 meter |
| gas source | 0.5~ 0.8MPa compressed air |
| Applicable coil type | Plastic film, metal foil, paper, non-woven fabric, etc |
| Spreader type | Water-based paints, solar-based paints, UV coatings, etc |
| application field | Encasement, electronics, construction, automotive, medical, etc |
| Operating Environment Temperature | 10℃ ~ 40℃ |
| Operating Environment Humidity | 30～90%RH |
| power requirements | 380V, 50Hz, three-phase five-wire system |
| total power consumption | 45KW (subject to actual customization) |
| dimensions | About 6000mm (total length of the frame 3m + 2 meters oven + 1 meter soaking) * 1200mm * 1600mm (subject to actual customization) |
| safety protection | emergency stop button |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
