Specifications
| coating method | continuous scratch coating |
| Effective Spreader Width | ≤ 300mm, adjustable through baffle |
| coating method | roller painting |
| Spreader roller diameter | Ф50mm |
| Spreader Film thickness range | 0.01mm~2mm |
| Film thickness | 0.01Mm (Depending on Stock, Reference Material Requirements) |
| Coating Surface Density | ≤ +/- 1.5% (including substrate, excluding edge anomalies) |
| coating speed | 2~ 4.5M/min forward and reverse stepless transmission |
| Film accuracy | +/- 0.003Mm (Depending on Stock, Reference Material Requirements) |
| Regulator resolution | 0.001mm |
| Indication display | digital display |
| Heating device | trough heating |
| Heating method | Heating rod |
| Temperature range | RT+~200℃ |
| box volume | About 0.5L |
| Drying area | Length 2000mm * Width 300mm |
| Drying temperature range | RT+~200℃ |
| Width of guide roller | 300mm |
| substrate width | Max.300mm |
| Back roller diameter | Ф150mm |
| Reel diameter | 3 inches. |
| rewinding diameter | Max.Ф450mm |
| Applicable materials | Lithium battery, glue, silicone oil, UV, inks, cataplasm, hot-melt adhesive, gel, plaster, Stock, etc |
| Applicable substrate | Paper, film, aluminum foil, plastic, non-woven fabric, etc |
| Machine power | 1050W |
| Host power supply | AC220V (single phase) 50Hz |
| Machine size | 1051 * 635 * 600mm (subject to actual customization) |
| Machine weight | About 120kg (subject to actual customization) |
Packing list
Equipment machine × 1, dial meter x2, power cord × 1, heating module x1, warranty card & manual x1, certificate of conformity x1
After-sales instructions
Warranty days: 365 days
