Specifications
| Measurement range | 0-2000μm |
| thinnest matrix | 0.3mm |
| Measurement accuracy | ±(1%-3%)H＋1.5μm |
| resolution | 0.1 μm /1 μm (0.1 μm below 100 μm, 1 μm above 100 μm) |
| Minimum matrix area | Φ11.5mm |
| minimum curvature | Convex 5mm; Concave 25mm |
| Dimension | 141（L）×69（W）×27（H）mm |
| weight | 242g |
| power supply | 3.7V lithium battery (3000mAH) |
| Operating Environment | Temperature 0 ℃ -60 ℃, Humidity 20% RH - 90% RH, use in a strong magnetic field environment, |
| optional | USB communication or Bluetooth function |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50713/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
