Specifications
| Measurement range | 0-10000μm(0-10mm) |
| thinnest matrix | 0.5mm |
| Measurement accuracy | ±3%H＋2μm |
| resolution | 0.1 μm /1 μm/0.01mm (0.1 μm below 100 μm, 1 μm above 100-9999, 0.01mm above 9999) |
| Minimum matrix area | Φ20.5mm |
| minimum curvature | Convex 10mm; Concave 50mm |
| Dimension | 141（L）×69（W）×27（H）mm |
| weight | 242g |
| power supply | 3.7V lithium battery (2000mAH) |
| Operating Environment | Temperature: 0 ℃ -60 ℃, Humidity: 20% RH - 90% RH, no strong magnetic field environment |
| optional | USB communication or Bluetooth function |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50715/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
