Specifications
| traverse speed | 1-150mm/s |
| Speed accuracy | Better than 1% |
| stroke length | 250mm |
| Maximum test drawing size | DIN A4 |
| Maximum test substrate thickness | 8Mm, with coating |
| Maximum application width | 200mm |
| Maximum test panel size (height including coating) | 300x200x8mm |
| maximum thickness | 40mm |
| Minimum bar length | 220 mm |
| wire diameter | 6-12.7mm |
| Drip capacity | 30ml |
| rate of descent | 1-150mm/s |
| Minimum Vacuum Level Required | -100mbar |
| Vacuum hole diameter | 1.3mm |
| distance between holes | 22mm |
| Number of vacuum holes | 117 |
| Vacuum connection | 6Mm connection |
| Size and weight | Depth: 335 mm /13, 18 in Width: 400 mm /15, 74 in Height: 190 mm/7,48 in Net weight: 12,5 kg /27, 55 lbs |
| power supply | 24VDC |
| power consumption | Max. 40W |
| display | 70X40mm, heating and lighting |
| Menu Language | English |
| control | 5-Key navigation switch |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
