Specifications
| Measurement condition | D/0 (Scattering Illuminant, 0 degree viewing angle) (in accordance with CIE No. 15, ISO 7724/1, ASTM E1164, DIN 5033 Teil7, JIS Z8722 Condition c.) ASTM D1209, ASTM D5386, ASTM D6045, ASTM D6166, ASTM D1502 |
| stand-alone operation | support |
| integrating sphere | φ 40mm, Avian-D full diffuse reflection surface coating |
| Illuminant | CLEDs (Full Band Equalized Led Illuminants) |
| Sensor | Dual Optical Path Sensor Array Sensor |
| Wavelength range | 360-780nm |
| wavelength interval | 10nm |
| Bandwidth | 5nm |
| Measurement range | 0~200% |
| resolution | 0.0001 |
| Observer Angle | 2°/10° |
| Observational Illuminant | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84,ID50,ID65,LED-B1,LED-B2,LED-B3,LED-B4,LED-B5,LED-BH1,LED-RGB1,LED-V1,LED-V4 |
| show | Pharmacopoeia color number, transmission chart/data, sample chromatic value, color difference value/chart, pass/fail result, Color bias, Color simulation, Historical data color simulation, Manual input of standard sample, Test report |
| Measurement time | ≤ 1.5 seconds |
| Measurement optical path | Standard: 10mm Glass Cuvette, 50mm Glass Cuvette (optional 33mm and 100mm Glass Cuvette) |
| Color space | CIE Lab, LCh, CIE Luv, XYZ, Yxy, Transmittance, Hunter Lab Munsell, MI, CMYK |
| Color difference formula | ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*02 |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
