Specifications
| coating method | scraping |
| coating speed | 1~500mm/S |
| Substrate fixing method | fixture fixing |
| Coating table material | Glass plate |
| Film accuracy | ±0.002mm |
| Coating table size | 840*430mm |
| effective coating area | 600 * 400Mm (can be customized) |
| Effective application width | 400Mm (width can be customized) |
| Effective application length | 600Mm (length can be customized) |
| Drawdown blade film thickness | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade type | Adjustable drawdown blade |
| Drawdown blade material | Die steel |
| Effective width of drawdown blade | 400Mm (can be customized) |
| Cutting head fixing method | Magnetic suction type (customized) |
| Drive motor | Servo motor |
| Power | 400w |
| display screen | Color LCD Touchscreen |
| Operating language | Chinese (can be customized in English) |
| Host power supply | 100V~220V/50~60HZ |
| Dimension | Subject to the actual product |
Packing list
Machine x1, drawdown blade x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/50811/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
