Specifications
| coating method | Bar + Drawdown blade |
| coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Marble countertop |
| Coating table size | 1040*630mm |
| effective coating area | 800 * 600Mm (can be customized) |
| meyer rod coating thickness range | Different bar sizes have different thicknesses, with High Accuracy imported bars |
| Bar accuracy | ±0.001mm |
| Blade Coating Thickness Range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Blade Coating Width | 600mm |
| Blade Coating accuracy | ±0.003mm |
| Drive motor | Servo motor |
| Power | 400w |
| Operating language | Chinese (can be customized in English) |
| display screen | Color LCD Touchscreen |
| Host power supply | 100V~220V/50~60HZ |
| Dimension | 1060 * 740 * 940Mm (subject to the actual product) |
| optional feature | Heating, Vacuum chuck |
Packing list
Host X1, manual X1, fixture X1, Drawdown blade x1, imported bar X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/51054/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
