Specifications
| station number | 1 station |
| Max. stirring Capacity | 20L |
| Input Power | 16W |
| output power | 9W |
| Display mode | LED |
| stirring speed | 0/50~1500rpm |
| Mixer size | 80mm |
| Heating output power | 600W |
| Heating rate | 6.5 K/min |
| Maximum heating temperature | 310℃ |
| Temperature control mode | LED |
| Temperature control Accuracy | ±1K |
| Speed regulation mode | stepless |
| Adjustable Safety Temperature Loop MIN Minimum | 50℃ |
| Adjustable Safety Temperature Loop MAX Maximum | 360℃ |
| Temperature Control Accuracy with Sensors | ±1K |
| Panel Material | aluminum alloy |
| Pan size | Φ135mm |
| Dimension | 160*85*270mm |
| Weight | 2.5kg |
| Environmental temperature | 5~40℃ |
| Protection level | IP42 |
| Power supply Voltage | 220~230/115/100V |
| Rated Frequency | 50/60Hz |
| Input Power | 650W |
Packing list
Host X1, temperature sensor X1, stirrer X1, strut X2, chuck X1, operation manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5455/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
