Specifications
| Measurement principle | Eddy Current |
| Measurement range | 0~625μm |
| margin of error | ±3% |
| Resolution | 0.1μm |
| probe | NAS1 probe (measurement of aluminum oxide film) |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| icon function | without |
| Power Supply | 3 * AAA alkaline battery |
| Standards | ISO 2178/2360/2808、PrEN ISO 19840、ASTM B499/D1186/D1400/D7091/E376/G12、BS3900-C5、SSPC-PA2等 |
| Calibrated Certificate | Yes. |
| Language | Chinese, English |
| Display screen | 2.8-Inch color touchscreen |
| Interface | USB |
| supporting software | PosiSoft Software Suite |
| Machine Weight | 137G (without battery) |
| Machine size | 127*66*25.4mm |
| Data storage | 1000 Measured values |
| Test environment | Non-ferrous metal substrate nonconductive coating environment |
| Defelsko calibrated standard | STDS2、STDA2 |
| screen image saving | One hundred. |
| Protection level | IP65 |
| Measurement speed | 60 + readings per minute |
Packing list
host x1, split probe x1, standard test piece (set) x1, rubber protective cover with waist clip x1, No. 7 battery x3, certificate x1, manual x1, nylon bag x1.
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer will be free of charge during the warranty period, and only the cost of spare parts will be charged outside the warranty period;
1-year warranty for the host and 6-month warranty for the probe, except for other accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/555/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
