Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity < 85% |
| Measurement range | 15~10000mN.m |
| error of indication | Below 50mN +/- 0.6mN, remaining +/- 1% |
| resolution | 0.1mN |
| Indication variability | ≤1％ |
| bending length | 50mm、25mm、20mm、15mm、10mm、5mm(±0.1mm) |
| bending angle | Adjustable from 0 to 90 degrees, commonly used 15 degrees/7.5 degrees |
| Test speed | 3S-30s (adjustable at 15 °) |
| printout | Built-in thermal printer |
| communication interface | RS232 |
| Dimension | 310*245*300mm |
| Weight | 13Kg (Net Weight) |
| Optional accessories | Stiffness Sampler, RS232 interface and microcomputer software (separately purchased) |
