Specifications
| Power supply Voltage | AC(100~240)V，(50/60)Hz |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity < 85% |
| Specimen size | Test plane ≥ 0019 30mm, thickness ≤ 40mm |
| Indication Precision | Color product coordinates ≤ 0.0008, the rest 0.01 |
| Measured value Stability | 30min after preheating, within the temperature range of +/- 5 ℃, ≤ 0.1 |
| Repeatability | Rx, Ry, Rz ≤ 0.03, chromaticity coordinates ≤ 0.0003, R457 ≤ 0.03 |
| Mirror reflection error | ≤0.1 |
| Built-in thermal printer | |
| Communication interface | Optional RS232 |
| Dimensions | 380*285*410mm |
| Net Weight | 12.5kg |
| Optional accessories | Whiteboard (3 #), Glass Cover, Simple Powder Press, RS232 Interface and Microcomputer Software |
Packing list
host X1, black cylinder X1, whiteboard (1 #, 2 #) X1, light bulb X1, printing paper X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
The instrument comes with a one-year warranty free of charge, and lifetime maintenance (except for human factors)
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5631/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
