Specifications
| Power supply Voltage | AC（220±10％）V, 50Hz |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity < 85% |
| Force range | 20~3000N |
| error of indication | ±1.0％ |
| Indication resolution | 1N |
| Indication variability | ≤1.0％ |
| Pressurization speed | 12.5±1mm/min |
| Up and down platen parallelism | <0.05mm |
| Maximum distance between Upper/Lower platens | 78mm |
| printout | Built-in thermal printer |
| Communication interface | RS232 |
| Dimension | 355*300*500mm |
| Net Weight of instrument | 41kg |
Packing list
host X1, printing paper X1, power cord X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5632/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
