Specifications
| Measurement range | 0.8~ 500Mm (standard mode); 3.0~20mm (coating mode), depending on the probe used, the material tested, and the surface condition |
| Probe style | Split probe |
| Measurement error | When resolution is 0.01mm, thickness H < 10mm, error of indication +/- 0.05mmWhen resolution is 0.01mm, thickness H ≥ 10mm, error of indication +/- (0.1% H + 0.05) mm When resolution is 0.1mm, error of indication +/- (1% H + 0.1) mm |
| Display resolution | 0.01Mm, 0.1mm optional |
| unit system | mm |
| Measurement mode | Pulse~ echo mode, echo~ echo mode, reverse measurement Speed of sound |
| Speed of sound | 1000~9999m/s |
| Display | LCD display (with backlight) |
| Operating language | Chinese |
| Application Software | none |
| Environmental temperature | -10~60℃ |
| Working Relative Humidity | <90%RH |
| Host size | 146*81*30mm |
| Weight | 300g |
| Data storage method | Storage method |
Packing list
host x1, probe x1, coupling agent x1, battery x2, instruction manual x1, warranty card x1, certificate x1, suitcase x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5735/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
