Kedian MC-3000A coated platings Thickness Gauge, thickness range 0~1200um

Kedian MC-3000A coated platings Thickness Gauge is a magnetic coated platings Thickness Gauge, which can measure the thickness of platings such as chrome plating, copper plating or paints, rubber, etc. The thickness measurement range of MC-3000A is 0~1200um.
Model：
Certificate
Contact
Details SPEC OI
Similar products

KODIN MC-3000A Coating Thickness GaugeSPEC

KODIN MC-3000A Coating Thickness GaugeDetails

KODIN MC-3000A Coating Thickness GaugePacking list

SKU
NB005736
Measurement principle
Magnetic Induction
Measurement range
0~1200μm
margin of error
±3%
Resolution
0.1μm
probe
Split F probe
statistical function
MAX Maximum, MIN Minimum, Average
Power Supply
2 * AA battery, continuous use time up to 200 hours
Calibrated Certificate
none
system language
Chinese
Display screen
3-Digit LCD digital display
supporting software
none
Machine Weight
360g
Machine size
146*81*30mm
Voltage prompt
Display icon in upper left corner
Storage method
Manually stored measurements
Data storage
100 Measured values, 6 groups
Operating temperature
0~40℃
shutdown mode
The shutdown mode can be manually set.
Keypad
6-Key waterproof, oil-proof keyboard
Relative Humidity
≤90%RH
MC-3000A
Coating Thickness Gauge
Kedian MC-3000A coated platings Thickness Gauge, thickness range 0~1200um Picture

Coating Thickness Gauge selector

Introduction

Kedian MC-3000A coating Thickness Gauge can easily and non-destructively measure the thickness of non-magnetic coating on ferromagnetic materials, such as zinc, copper, chromium or the thickness of paint, enamel, fiberglass, rubber, spraying, asphalt and other coatings on the surface of steel;

MC-3000A Coating Thickness GaugeKey features

● Basic measurement mode: regular mode, minimum mode, statistical mode

●Monitoring and measurement mode: the difference can be set, and the upper and lower limit alarm settings can be set

● You can delete and store a single data, a group of data, or all data

●Zero-point calibration, two-point calibration and system calibration can be performed

●The shutdown mode can be set, the backlight is turned on or off, and the factory state can be restored

●Stored values can be printed, and statistical values can also be printed

●There are 6 groups of data stored in groups, and each group stores 100 measurement points

●Stored measurements can be viewed in groups

Product display diagram

Details of the HCH-3000E/E high-precision ultrasonic Thickness Gauge

FAQ
QHow to use the MC-300A model thickness gauge?
A Hello, regarding the operation instructions for the MC-300A thickness gauge, it is recommended that you click "Operation Manual" on this product page to view.
QCan MC-3000A Coating thickness gauge automatically determine whether the test exceeds the limit?
A Hello, yes, this thickness gauge has monitoring measurement mode, the user can customize the upper and lower limits of the alarm to monitor whether the workpiece Film thickness is qualified in real time, once the measurement data exceeds the upper and lower limits, the instrument will display the overlimit symbol, and through the urgent alarm sound to prompt the user.
QCan MC-3000A test curved workpieces? Is it accurate?
A Hello, yes, but in the measurement of curved surfaces and cylinders, if the radius of curvature is small, it should be calibrated on the uncoated workpiece to ensure the measurement accuracy.
