Specifications
| Film thickness range | 0.05~ 10mm (instruments for detecting anti-corrosion layers above 10mm can also be provided according to user needs) |
| Output high Voltage | 0.6KV~ 30KV (stepless continuous adjustable) |
| Power Supply | 12V/2800mA |
| Resolution | 100W |
| Host size | 220*130*88mm |
| Battery | 12V/2800mA |
| power consumption | Approx. 5W |
| Automatic shutdown | Background light, instantaneous power on, automatic power off and shutdown |
| alarm | earphones, buzzer double alarm, light alarm |
| Host Weight | 2.2Kg, with box 6kg |
Packing list
Host x1, high voltage probe x1, probe brush x2, connecting rod x1, earphone x1, strap x1, fuse x1, manual x1, warranty card x1, certificate x1, Encasement box x1, grounding wire x1, charger x1
After-sales instructions
Warranty days: 365 days
【After-sales Instructions】
1. After-sales service is provided by the original factory;
2. The main engine is guaranteed for one year, and the accessories are guaranteed for three months;
3. The following two situations need to be repaired for a fee:
A. It is used under normal conditions, and there is a failure, but it has exceeded the one-year warranty period;
B. Use under abnormal circumstances, including man-made physical damage, failure to operate in accordance with the instructions and precautions.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5745/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
