Specifications
| number of ways | 20 channels (scanning measurement) |
| Measurement parameter | DC resistance |
| Basic Precision | 0.05% |
| Measurement range | 1μΩ~30KΩ |
| signal source | Current: < 1A |
| range | Automatic and manual |
| Test speed | Fast, slow speed adjustable |
| Show results | 20-Way direct reading display |
| Maximum reading | 30000 |
| correction | Short circuit clearing in full scale |
| comparator | 10 channels set individually |
| trigger method | Internal triggering and remote triggering |
| standard interface | RS-232C interface (SCPI Instruction Set Architecture) HANDLER interface (PLC interface) |
| temperature compensation | Precision: 0.2 ℃ Temperature range: 0~80 ℃ |
| test side | 4-End Shielding per channel (including 2 detection terminals and 2 drive terminals) |
| other | True color LCD display, can set the Upper/Lower limits of resistance, with temperature compensation function keypad lock |
| power requirements | Voltage: 198VAC~ 250VAC Frequency: 50Hz Power: Maximum 15VA |
| Size and Weight | Outer Dimensions (mm): 264 (W) x107 (H) x350 (D) Inner Dimensions: 216 (W) x88 (H) x323 (D) Weight: 4kg |
Packing list
Host x1, ATL501 Kelvin clip x20, ATL801 232c communication cable x1
