Defelsko PosiTector 6000 NS1 galvanized Thickness Gauge, non-ferrous metal (aluminum, copper) substrate nonconductive coating

SE
Eddy Current, thickness measurement 0~1500μm, error range +/- 1%; Probe waterproof, non-slip and wear-resistant probe with built-in temperature compensation function; can flip the display touch LCD screen, support screenshots; with sound and visual alarm; USB interface can transmit data and charge.
$1045.00/set
PromotionLoading...
Coupon
Certificate
Contact
Details SPEC Con VIDEO CAT OI
Similar products

Defelsko PosiTector 6000 NS1 Coating Thickness GaugeSPEC

Defelsko PosiTector 6000 NS1 Coating Thickness GaugeDetails

Defelsko PosiTector 6000 NS1 Coating Thickness GaugePacking list

SKU
NB000583
Measurement principle
Eddy Current
Measurement range
0~1500μm
margin of error
±1%
Resolution
0.1μm
probe
NS1 Probe (Universal)
statistical function
Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation
icon function
without
Power Supply
3 * AAA alkaline battery
Standards
ISO 2178/2360/2808、PrEN ISO 19840、ASTM B499/D1186/D1400/D7091/E376/G12、BS3900-C5、SSPC-PA2等
Calibrated Certificate
Yes.
Language
Chinese, English
Display screen
2.8-Inch color touchscreen
Interface
USB
supporting software
Yes.
Machine Weight
137G (without battery)
Machine size
127*66*25.4mm
Data storage
1000 Measured values
Test environment
Non-ferrous metal substrate nonconductive coating environment
Defelsko calibrated standard
STDS1、STDA1
screen image saving
One hundred.
Protection level
IP65
Measurement speed
60 + readings per minute
PosiTector 6000 NS1
Coating Thickness Gauge
Eddy Current, thickness measurement 0~1500μm, error range +/- 1%; Probe waterproof, non-slip and wear-resistant probe with built-in temperature compensation function; can flip the display touch LCD screen, support screenshots; with sound and visual alarm; USB interface can transmit data and charge.
Defelsko PosiTector 6000 NS1 galvanized Thickness Gauge, non-ferrous metal (aluminum, copper) substrate nonconductive coating Picture

Coating Thickness Gauge selector

Introducing the PosiTector 6000 NS1 Aluminum Plate Coating Thickness Gauge

The Defelsko PosiTector 6000 NS1 Coating Thickness Gauge is a standard coating Thickness Gauge with an all-in-one structure design, and the Positector 6000 series coating Thickness Gauge is available in advanced and standard modelsThe PosiTector 6000 NS1 Coating Thickness Gauge is a 250-reading data store that can be viewed and downloaded via a PC connection for further data management and data analysis.The PosiTector 6000 NS1 Coating Thickness Gauge uses an eddy-current Thickness Gauge with a measurement range of 0~1500 microns.

New features have been added to the new version of the Defelsko PosiTector console in the United States

Defelsko Devs high brand introduction

Defelsko PosiTector 6000 NS1 galvanized Thickness Gauge probe accuracy

The Defelsko PosiTector 6000 Coating Thickness Gauge can be equipped with a variety of transducers

Comparison of the features of the Defelsko PosiTector 6000 Advanced and Standard models in the United States

Protective benefits of the Defelsko PosiTector 6000 NS1 galvanized Thickness Gauge

Additional features of the Defelsko PosiTector 6000 NS1 galvanized Thickness Gauge

Typical application area of the Defelsko PosiTector 6000 NS1 galvanized Thickness Gauge

Why Choose the Defelsko PosiTector 6000 NS1 Galvanized Thickness Gauge from the United States?

Recommended reading

★《How do you choose the Defelsko PosiTector 6000 Coating Thickness Gauge?》

★Defelsko PosiTector 6000 Series Coating Thickness Gauge Details (Text Version)

FAQ
QI need a thickness gauge with data storage function. Is this one suitable?
A Suitable! The PosiTector 6000 NS1 has a built-in data storage capacity of 1000, and can also export data through a USB connection computer. The supporting software is convenient for data management and analysis. It is suitable for Quality control work that requires recording and tracing coating thickness data.
QCan this model be tested for iron base?
A No, if you want to measure non-iron and iron, it is recommended to use the dual-function 6000 FNS1 model.
QCan copper nickel plating, tin plating, gold plating, aluminum nickel plating?
A In addition to nickel, Miscellaneous non-ferrous platings can be tested
QMeasure aluminum coating, about 20-30um, the minimum workpiece is 18 * 25cm, the maximum is 40 * 50cm
A Defelsko ns1 is suitable. Note that if the surface is curved, please provide the surface curvature data.
QNeed coating related tester what advice, chrome plating can be measured?
A This one is ok.
QIs there a thickness gauge that can detect molybdenum disulfide on titanium alloys? 7-12um thickness
A Titanium alloys are non-magnetic materials, which can be measured by the eddy Current method, and 6000NS1 can be
QCoating a layer of inks on a tin-lead alloy, inks dry-film thickness is about 20μm, do you have an instrument that can test the thickness of inks?
A Recommendation 6000NS1
QCan you test the thickness of metallic coatings? Aluminum alloy, 150-200 microns, the surface is like sand, very rough polyester powder coating
A It is not suitable to measure this rough surface. The PosiTector 6000 NS1 can measure it, but the error caused by roughness is large, so a Miscellaneous probe can be selected.
QDo the Defelsko 6000 series thickness gauges come standard with software?
A This does not have a physical software CD, but PosiSoft software can be downloaded for free on the manufacturer's official website for downloading and viewing data reports.
QDefelsko PosiTector 6000 NS1 Can this galvanized thickness gauge measure the paints Film thickness on steel plates? about 0.5mm
A Hello, it's OK.
