Specifications
| Model | AT512 |
| Measurement parameter | DC resistance |
| Basic Precision | 0.01% |
| Measurement range | 0.1μΩ~110MΩ |
| signal source | Maximum current: 1uA~ 1A |
| range | 11 range automatic and manual |
| Measurement speed | 150 times/second, 10 times/second, 2 times/second |
| Show results | Direct reading, delta ABS, delta% and sorting results |
| Maximum reading | 104000 |
| correction | Open and short circuit clearing |
| comparator | 30 sets of comparators, display and output NG-LO, GD-IN, NG-HI sound and adjustable Volume |
| trigger method | Internal, manual, external, remote triggering |
| interface | RS232C, Handler interface (PLC interface) |
| temperature compensation | Temperature range: 0~80 ℃ Precision: 0.2 ℃ |
| test side | 4-Terminal Shielding (including 2 detection terminals and 2 drive terminals) and outer Shielding ground terminals |
| Miscellaneous | Four-color vacuum fluorescent screen VFD display, keypad lock and data retention function temperature compensation function |
| power requirements | Voltage: 198VAC~ 240VAC Frequency: 50Hz Power: Maximum 15VA |
| size | Outer Dimensions (mm): 264 (W) x107 (H) x350 (D) Inner Dimensions: 216 (W) x88 (H) x323 (D) |
| Weight | 4kg |
Packing list
Host x1, ATL501: Four-terminal Kelvin clip test cable x1, ATL801:232 communication cable x1
After-sales instructions
Warranty days: 730 days
