Specifications
| Measurement parameter | DC resistance |
| Basic Precision | 0.2% |
| Measurement range | 10μΩ~200kΩ |
| signal source | Maximum current: < 100mA |
| range | Eight-range automatic and manual testing |
| Test speed | Slow speed: 3 times/second, fast speed: 10 times/second |
| Show results | direct reading |
| Maximum reading | 5000 |
| correction | Short circuit clearing in full scale |
| comparator | OFF (Off) PASS (Pass) HI (High) LO (Low) |
| sound | GD, NG, Off Settings |
| test side | 4-Terminal Shielding (including 2 detection terminals and 2 drive terminals) and outer Shielding ground terminals |
| other | 0.8-Inch LED display |
| application | Measurement of small Wire diameter coil internal resistance (such as earphone coil); Sensors resistance value measurement; protection device resistance value measurement; ordinary transformers, Inductance devices, motors, deflection coil winding resistance, various contact resistance; solder joint contact resistance; metal flaw detection, etc |
| power requirements | Voltage: 198VAC~ 240VAC Frequency: 50Hz Power: Maximum 15VA |
| size | 220 (W) x85 (H) x259 (D) |
| Weight | 2kg |
Packing list
Host x1, ATL503: Four-terminal Kelvin clip test line x1
After-sales instructions
Warranty days: 730 days
