Specifications
| Measurement parameter | AC resistance, DC Voltage |
| Basic Precision | Resistance: 0.2% Voltage: 0.01% |
| Measurement range | Resistance: 0.001mΩ~ 33.000kΩ Voltage: 0.00001V~ 120.000VDC |
| signal source | AC 1kHz |
| range | Seven range automatic and manual |
| Test speed | 145 times/second, 30 times/second, 10 times/second, 1 time/second |
| Show results | Direct reading, sorting results |
| Maximum reading | Resistance: 33,000 Voltage: 1,200,000 |
| correction | Short circuit clearing in full scale |
| comparator | RHI/RNG/RLO output VHI/VNG/VLO output, absolute tolerance +/- TOL sorting, percentage tolerance TOL sorting, sequential comparison sorting |
| trigger method | Internal trigger, manual trigger, external trigger and remote trigger |
| standard interface | RS-232C interface USB interface Handler interface (PLC interface) RS-232C interface USB interface |
| other | True color TFT-LCD display, keylock and data retention function, internal flash memory and U disk data recording |
| power requirements | Voltage: 110VAC/240VAC Frequency: 50Hz Power: Maximum 15VA |
| size | External Dimensions (mm): 264 (W) x107 (H) x350 (D) |
| Weight | 4kg |
Packing list
Host x1, Kelvin clip x1, RS232C communication cable x1
After-sales instructions
Warranty days: 730 days
