APPLENT AT4710 multi-channel temperature Tester 10 channels 50ms/channel scanning speed
AT4710
Applent AT4710 Multichannel temperature TesterSPEC
Applent AT4710 Multichannel temperature TesterDetails
Applent AT4710 Multichannel temperature TesterPacking list
- SKU
- NB005859
- parameter
- Thermocouple: J/K/T/E/S/N/B/R/W type
- Basic Precision
- 0.2 ℃ +/- 2 characters (excluding Thermocouple)
- Temperature Measurement Range
- -270~1820℃
- Number of channels
- 10 channels
- Sampling rate
- 50ms/channel
- correction
- error correction per channel
- comparator
- The Upper/Lower super alarms are set separately for each channel, and the alarm signal can be output through HANDLER
- Interface
- RS232C interface U disk interface, SD card interface USB Communication interface HANDLER interface
- Standard software
- ATS46 data collection software
- Power protection
- Maximum 300V AC/DC live test
- cold junction compensation
- Precision: 0.1 ℃
- Power Supply
- Voltage: 85VAC~ 260VAC Frequency: 50Hz/60Hz Power: 30VA
- Dimension
- 290*130*360mm
- Weight
- 5kg
Introduction
The AMMG AT4710 multi-channel temperature Tester uses a high-performance ARM microprocessor andFPGA control, using a 7-inch LCD screen with touch function, can be used at the same timeMultiple temperature, Voltage, and resistance data can be collected separately or mixed, and the data can be exceededAlarm and communication transmission, and can be extended to 40 channels of temperature dataAccommodating a variety of temperature sensors, 1ms/channel ultra-fast response speed, stable data,At the same time, it has the function of breaking the couple.
AMBER AT4710 multi-channel temperature Tester has a built-in LAN interface, supports RS-232 interface and USB communication connectionMouth, through the standard computer software can realize data acquisition, analysis and playingStamp. Support network communication functionSupport USB disk memory to store sampling data in real time. Users can be interested in:Each channel of data is independently calibrated.
Performance characteristics
● 7-inch touch screen display, three display fonts
●High-speed sampling using real-time FPGA circuit
●Cold junction compensation: Multi-signal mixed sampling
●High Voltage isolation circuit is adopted
●Standard USB disk interface, support large-capacity storage devices.
●Standard RS232C interface
●Built-in large-capacity data buffer, real-time data recording
●Automatic detection of broken couples
●The instrument has a comparator function
●AT46 data acquisition software is standard
Application
It is suitable for manufacturers and quality inspection departments of home appliances, motors, electric heating appliances, thermostats, transformers, ovens, thermal protectors, power supplies, lighting, electric power, LED and other industries to test multi-point temperature and fuel cells, electric vehicle batteries, lithium battery packs, lead-acid battery packs R & D and maintenance, LED and related circuit research and development, evaluation and testing of automobiles and their parts, daily maintenance of automation and other equipment, plant monitoring, measurement of electronic components such as power devices, etc
Amber Multi-way Temperature Tester Selection Table
