Specifications
| indexing mark | Thermocouple: J/K/T/E/S/N/B/R/type |
| Basic Precision | 0.2% + 1 ℃ (excluding Thermocouple) |
| Temperature Measurement Range | -200~1300℃ |
| resolution | 0.2 ℃ +/- 2 characters |
| Number of channels | 8 channel |
| Sampling rate | Fast: 100ms Medium speed: 500ms Slow speed: 1s |
| correction | error correction per channel |
| comparator | Up and down super alarm (set up and down super value separately for each channel) |
| Interface | U disk interface, Mini-USB (virtual serial port) |
| Standard software | ATS45 data collection software |
| cold junction compensation | Precision: 0.5 ℃ |
| other | TFT-LCD true color liquid crystal display, even detection function |
| Power Supply | Input: 100-240V~ 50/60Hz 0.35A Output: 9V 1A DC |
| Power Supply | 8.4V, Li, 2200mAh rechargeable battery |
| Power Supply | Charging time: 300Min max. |
| Battery life | ≥ 8 hours |
| Dimension | 130.23 *210.76*37.88mm |
| Weight | 650g |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5865/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
